For a 130 cm opening, investigate only 55MNH7000Z among these three METZ models: its 122.6 cm cabinet leaves 7.4 cm total before required clearances. If several sizes fit elsewhere, compare their apparent image size from your real seat, then total setup cost. The original 16:9 calculations below illustrate that choice; they are not medical advice, a mandatory standard or a METZ distance prescription.
Only 55MNH7000Z is narrower than the opening, at 122.6 cm. The 134.5 cm-wide 60MNH7000Z and 144.5 cm-wide 65MNH7000Z cannot fit within 130 cm. The smaller cabinet's 7.4 cm total numerical margin comes before ventilation, cable access and any required clearance. Treat it as a candidate for checking, not permission to enclose the television.
Measure the clear opening independently and do not round dimensions to rescue a preferred size. Include sockets and access to connections on the sketch. If the instructions or support arrangement rule out the smaller option too, change the layout rather than forcing a television into the recess. An alternative wall position may also improve seating and reflections, making the room more useful without requiring a larger diagonal.
Use the supplied cabinet dimensions rather than calculated image width for physical planning. With-base and without-base figures are width x depth x height in centimetres; base footprint is width x depth. Without-base depth does not include a bracket, cable bends or clearance from the wall. A thin-looking cabinet can still need a deeper installed arrangement.
Keep full cabinet and base measurements visible together. The base envelope does not establish a minimum shelf size, acceptable overhang or load capacity. Check support geometry, furniture strength and stability separately, along with the instructions. A numerical match is only one part of a complete installation decision, particularly near the edges of a narrow surface.
| Model | With base, cm | Without base, cm | Base footprint, cm |
|---|---|---|---|
| 55MNH7000Z | 122.6 x 26.4 x 78.3 | 122.6 x 8.1 x 71.8 | 85.7 x 26.4 |
| 60MNH7000Z | 134.5 x 29.9 x 85.8 | 134.5 x 8.8 x 78.8 | 116.9 x 29.9 |
| 65MNH7000Z | 144.5 x 29.9 x 91.3 | 144.5 x 9.2 x 83.8 | 131.5 x 29.9 |
Assume a flat 16:9 active image and the nominal diagonal in inches. Image width W = diagonal x 2.54 x 16 / sqrt(337); height replaces 16 with 9. The resulting estimates are 121.8 x 68.5 cm for 55 inches, 132.8 x 74.7 cm for 60 inches and 143.9 x 80.9 cm for 65 inches. These are original geometric calculations, not new measurements of METZ panels.
For a centred eye at distance d, horizontal field of view equals 2 x atan(W / (2d)). At an example 250 cm eye-to-screen distance, the three nominal images span approximately 27.4, 29.8 and 32.1 degrees. This describes apparent scale. It does not predict individual eyesight, subtitle comfort, side-seat performance or the quality of your programme source.
To explore another preference, assume a 30-degree horizontal angle and solve d = W / (2 x tan(15 degrees)). The corresponding example distances are about 227, 248 and 269 cm. Thirty degrees is a declared assumption here, not a medical limit or mandatory standard. THX publishes its own size-distance rule of thumb; that contextual guidance is not the same formula and does not validate a METZ model. [S1]
For a 120 x 32 cm usable surface, the 60-inch base footprint of 116.9 x 29.9 cm leaves 3.1 cm total width and 2.1 cm total depth numerically. Its full cabinet is still 134.5 cm wide. These small margins do not prove safe support. Check edge positions, complete support geometry, cable needs and instructions rather than assuming the base envelope settles the issue.
The 65-inch base, 131.5 x 29.9 cm, exceeds that surface width. The 55-inch footprint, 85.7 x 26.4 cm, is smaller, while its cabinet is 122.6 cm wide. That produces different follow-up questions, not automatic installation approvals. If the surface cannot satisfy the chosen model's complete arrangement, change furniture or mounting before spending time on picture comparisons for an unusable size.
Possibly, if it removes the support constraint without creating another problem. Wall mounting does not reduce cabinet width. The documented VESA pattern is 200 x 200 mm for 55MNH7000Z and 60MNH7000Z, and 400 x 200 mm for 65MNH7000Z. Listed weights without base are 9.6, 11.9 and 13.9 kg respectively. Match the bracket, wall structure and fixings to the relevant instructions.
Do not infer screw specifications or wall capacity from hole spacing alone. An extending arm also changes the installed geometry and load arrangement. Return to the seat after choosing the mounting position: a screen raised to clear furniture may be awkward for a long film. Check nearby lamps, doorways and routes before deciding that mounting has genuinely solved the original constraint.
Mark an image outline at the proposed height and sit in your usual posture. Compare the main seat and least central regular seat. If the example distance resembles your room, consider whether the roughly 4.7-degree increase from nominal 55 to 65 inches at 250 cm is welcome. An outline tests scale only; it cannot reproduce reflections, contrast or panel behaviour. Use familiar content on the exact television for those questions.
Set one total budget covering necessary setup changes, then compare current exact-model quotations. Preserve proper support before optional size. All three METZ models document QD-MiniLED, 3840 x 2160, Google TV and WiFi-WLAN/LAN. Confirm essential Italian-market services. For films, sport or games, name the remaining performance condition separately: dark-scene presentation, movement or intended-source response. A larger diagonal does not automatically improve any of those outcomes.
METZ measurements and configuration come from the checked supplied datasheets and installation record. [S0] Image dimensions and viewing angles are original calculations using nominal diagonals and stated assumptions; they are not measured active-area specifications. THX provides contextual guidance only. [S1] No site survey, picture test, current price or warranty outcome is asserted. Your final statement should name the model, why its installation and scale fit, and the one essential check that could still change the decision.
Only 55MNH7000Z is narrower, at 122.6 cm. Its 7.4 cm total remaining width precedes required clearances. The wider two cabinets are excluded; support, ventilation and instructions can still rule out the smaller model.
A nominal 16:9 image spans about 27.4 degrees at 55 inches, 29.8 at 60 and 32.1 at 65. It compares apparent image size for a centred eye, not medical comfort or tested METZ picture quality.
No. About 227, 248 and 269 cm are calculated examples for nominal 55, 60 and 65-inch 16:9 images. The angle is a declared preference assumption, not a medical threshold, mandatory standard or unique manufacturer recommendation.
No. It can remove a furniture constraint but not cabinet width. Check VESA, weight, bracket suitability, wall structure, fixings and the instructions. Then reassess screen height, cable access and comfort from the actual seats.
Access recorded: 2026-10-15
Supports: Per-model dimensions, footprints, VESA, weights and configuration
Scope: Local records: content/preflight/metz-supplied-material-recheck-20261012.json and content/preflight/metz-installation-preview-implementation-20261012.json; Manufacturer-stated specifications, not independent tests or installation approval
Access recorded: 2026-10-15
Supports: Published seating-distance and diagonal rule of thumb; Screen-centre alignment consideration
Scope: Not medical advice or a universal distance rule; THX's multiplier is not the article's exact 30-degree calculation; No certification or testing of named METZ models inferred; product suggestions not reused
